Sleeping Beauty
NetBSD on modern laptops
Jörg Sonnenberger
joerg@NetBSD.org
Jared D. McNeill
jmcneill@NetBSD.org
Outline
- Motivation & Goals
- The NetBSD Powermanagement Framework (PMF)
- The ACPI infrastructure
- Video devices
- Outlook
Motivation
- My laptop is my office.
- Lenovo finally stopped full APM support, most other vendors earlier.
- APM and SMP don't play well.
- APM and AMD64 don't play well either.
- Travelling around Germany drains the battery a lot.
Goals
- Suspend-to-RAM of a live system
- Manual disabling of unused devices
- Power-saving for inactive devices
- Inter-driver notification messages
PMF
- Device interface
- Event interface
Device interface of PMF
- Device power management in layers:
- Device,
- Bus,
- Class
- Suspend: Class -> Device -> Bus
- Resume: Bus -> Device -> Class
- Handler failed -> whole transition cancelled
The PCI/Cardbus bus handling
- Suspend:
- Capture generic part of the configuration space
- Disable address decoding and bus mastering
- Transition to D3 state
- For Cardbus, optionally turn off power
- Resume:
- For cardbus, turn on power
- Transition to D0 state
- Restore generic part of the configuration space
- Shutdown:
- Disable address decoding and bus mastering
The network class handling
- Register passes down the associated interface
- Suspend calls if_stop
- Resume calls if_init and if_start if IFF_UP is set
- Logic to deactivate device if interface is down
- Enough for most network drivers
The audio class handling
- Exploits device tree to find physical device
- Suspend saves current mixer settings and stops play back / recording
- Resume restores mixer settings and restarts play back / recording
- Optional code to suspend audio device after 30 seconds
- Event handlers for volume up / down / toggle
System interface
- low: pmf_device_suspend and pmf_device_resume
- medium: pmf_device_recursive_suspend, pmf_device_recursive_resume, pmf_device_resume_subtree
- high: pmf_system_suspend, pmf_system_resume, pmf_system_shutdown
Event interface
- Send event notifications to specific devices or the whole system
- Primary example: hot keys
- Pure userland solution too quirky
- Events are exposed via sysmon to userland
- Currently implemented:
- Lid open / close
- Volume up / down / toggle
- Display on / off / brighter / darker
ACPI infrastructure
- ACPI Component Architecture (ACPICA) was old, update needed
- ACPI Embedded Controller (EC) needed work for that
- ACPI Suspend-to-RAM support for AMD64 and SMP
ACPICA update (I)
- Many bug fixes in newer release from Intel
- Newer release not available from the Intel site, FreeBSD had them
- Many function signature changes
- New ACPICA showed locking issues in the EC driver
ACPICA update (II)
- ACPI Initialisation was difficult:
- Interrupt Routing tables not parsed when ACPI System Configuration Interrupt (SCI) is set up
- Deferred Interrupt setup as workaround
- Split the initialisation:
- Just initialise the system enough to read the MADT
- Parse the MADT and prepare Interrupt Routing
- Finish the initialisation
ACPI EC rewrite (I)
- Used by ACPI Virtual Machine to access slow hardware
- Used to inform ACPI Virtual Machine about hardware events
- Very simple hardware protocol
ACPI EC rewrite (II)
ACPI EC rewrite (III)
- Two one-byte ports
- Query: Put reason for a SCI into the data buffer
- Read: Read address from data buffer and write current value back
- Write: Read address from data buffer followed by new value
- Enable burst: request attention from EC for back-to-back transfer
- Disable burst: release EC
ACPI EC rewrite (IV)
- Before:
- Mix of polling and interrupt mode
- Interleaved code paths
- Difficult to lock correctly
- After:
- Kernel thread for handling SCIs
- Read and write function as public interface
- Exclusive lock on the entry points
- State machine driven either by explicit polling or interrupts
